The working principle of the two-stage double screw air screw air compressor:
The double compression screw host adopts two-stage sub-compression. After the first-stage compression, the oil and gas can be fully mixed between the stages, reducing the suction temperature of the second-stage compression, thereby reducing power consumption.
1. After the first-stage compression, the oil and gas can be fully mixed between the stages to reduce the suction temperature of the second-stage compression, thereby reducing the power
2. consumption.
3. Two-stage compression replaces single-stage compression, and the displacement increases by nearly 15%, which can achieve an energy saving effect of up to 15%.
4. The compression ratio of each stage of compression reduces bearing loads.
5. The compression ratio of each stage is small, the leakage is smaller, the volumetric efficiency is high; the vibration and noise are low.
6. Under the same power, the two heads bear the load, the bearing is less stressed and the service life is longer.
To put it simply, using a smaller motor to achieve a larger displacement!
the energy saving effect is 35-40% higher than that of ordinary screw air compressors, and 15% higher than that of ordinary variable frequency air compressors.
Specification :
Model
Modelo
HGV-22A
HGV-30A
HGV-37A
HGV-45A
HGV-55A
HGV-75A
HGV-90A
air flow
flujo de aire
m3/min
4.2
4.1
3.5
3.2
6.7
6.5
5
4.3
7.2
7.1
6.3
5.4
10.3
10
8
6.5
12.8
12.5
9.6
8.6
17.5
17
13
11.2
20.8
19.8
19.6
14.3
cfm
148
144
123
112
236
229
176
151
254
250
222
190
363
353
282
230
451
441
339
303
617
600
460
395
734
699
692
504
working pressure
presión laboral
bar(kg)
7
8
10
12.5
7
8
10
12.5
7
8
10
12.5
7
8
10
12.5
7
8
10
12.5
7
8
10
12.5
7
8
10
12.5
psi
102
116
145
174
102
116
145
174
102
116
145
174
102
116
145
174
102
116
145
174
102
116
145
174
102
116
145
174
power
poder
KW / HP
22kw/
30hp
30kw/
40hp
37kw/
50hp
45kw/
60hp
55kw/
75hp
75kw/
100hp
90kw/
120hp
noise
db(A)
68±2
68±2
68±2
74±2
74±2
74±2
83±2
Caliber
inch
RP 1
RP 1
RP1 1/2
RP1 1/2
RP2
RP2
RP2
Voltage/Frequency
AC 380v/415v/220v/480v or 50hz/60hz accpet Customized voltage
Starting mode
Modo de inicio
variable frequency staring / inicio de frecuencia variable
lubricant oil
liter
26
36
36
65
65
65
100
Shape dimension
(mm)
L
1500
1660
1660
2180
2180
2180
2500
W
1000
1085
1085
1360
1360
1360
1600
H
1250
1400
1400
1660
1660
1660
1840
Weight
KG
620
820
820
1860
1860
1860
2800
Model
Modelo
HGV-110A
HGV-132A
HGV-160A
HGV-185A
HGV-200A
HGV-220A
HGV-250A
air flow
flujo de aire
m3/min
25
24
20
18
30
28
25.5
20
34.5
33.6
30
24
41
38.4
32.5
28.6
44.6
43
38.5
32.8
49.5
48
41
38
55.5
54
46
40
cfm
865
829
695
621
1059
982
900
699
1218
1186
1659
840
1447
1355
1147
1009
1574
1518
1359
1158
1748
1694
1447
1341
1959
1906
1624
1412
working pressure
presión laboral
bar(kg)
7
8
10
12.5
7
8
10
12.5
7
8
10
12.5
7
8
10
12.5
7
8
10
12.5
7
8
10
12.5
7
8
10
12.5
psi
102
116
145
174
102
116
145
174
102
116
145
174
102
116
145
174
102
116
145
174
102
116
145
174
102
116
145
174
power
poder
KW / HP
110kw/
150hp
132kw/
175hp
160kw/
210hp
185kw/
250hp
200kw/
275hp
220kw/
300hp
250kw/
335hp
noise
db(A)
78±2
85±2
82±2
82±2
84±2
90±2
90±2
Caliber
inch
RP2, 1/2
RP2, 1/2
DN80
DN100
DN100
DN100
DN100
Voltage/Frequency
AC 380v/415v/220v/480v or 50hz/60hz accpet Customized voltage
Starting mode
Modo de inicio
variable frequency staring / inicio de frecuencia variable
lubricant oil
liter
120
120
140
140
170
200
200
Shape dimension
(mm)
L
2500
2500
3600
3600
3860
400
400
W
1600
1600
2100
2100
2100
1780
1780
H
1840
1840
2200
2200
2280
1968
1968
Weight
KG
3100
3100
3800
3800
5100
6500
6500
